CIR150A
产品描述
中低风压潜孔冲击器及钻头 CIR系列潜孔钻头
Middle＆Low air pressure DTH hammers and drill bits CIR series DTH drill bits
直径 Diameter | 合金数量、直径 No x Buttons diameter mm | 角度 Button angle°
| 气孔 Air holes | 重量 Weight (Kg) | 编号 Part No | ||
mm | inch | 边齿 Gauge | 中齿 Front | ||||
CIR150A冲击器用钻头 Drill bits for CIR150A hammers | |||||||
155 | 6 1/5 | 9x16 | 6x16+3x14 | 45 | 3 | 16.6 | CIR150A-155DVC9 |
165 | 6 1/2 | 9x16 | 6x16+4x14 | 45 | 3 | 18.6 | CIR150A-165DVC9 |
180 | 7 | 9x16 | 9x16+4x14 | 45 | 3 | 20.8 | CIR150A-180DVC9 |
200 | 8 | 9x16 | 9x16+4x14 | 45 | 3 | 23 | CIR150A-200DVC9 |
